The MC Windfeld Ti

A moving coil phono cartridge in the absolute high-end class
Our extensive knowledge of vibration properties, characteristics in different shapes and materials, competences in magnetism, mechanical design and new technologies has been applied for optimization of the MC Windfeld model. The MC Windfeld Ti has gone to the next level by reducing unwanted vibrations and increasing the dynamic capability of the cartridge.

MC Windfeld Ti Technical data

• Output voltage at 1000 Hz, 5cm/sec. - 0.2 mV
• Channel balance at 1 kHz - 0.5 dB
• Channel separation at 1 kHz - 25 dB
• Channel separation at 15 kHz - 20 dB
• Frequency range at - 3dB - 10 Hz - 50 kHz
• Frequency response - 20 Hz - 20 kHz +2 dB/- 1 dB
• Tracking ability at 315Hz at recommended tracking force - 90 µm
• Compliance, dynamic, lateral - 13 µm/mN
• Stylus type - Special polished Nude Ortofon Replicant 100 on Boron Cantilever
• Stylus tip radius - r/R 5/100 µm
• Tracking force range - 2.0-2.5 g (20-25 mN)
• Tracking force, recommended - 2.3 g (23 mN)
• Tracking angle - 23°
• Internal impedance, DC resistance - 7 Ohm
• Recommended load impedance - > 10 Ohm
• Coil wire material - Aucurum
• Cartridge body material - SLM Titanium and Stainless Steel
• Cartridge colour - Titanium/Black
• Cartridge weight - 11 g
